Oil-immersed non-partial discharge transformer

ProductOverview

Oil-immersed Non-Partial Discharge Transformer for High Voltage Insulation Testing

SUTE Oil-immersed Non-Partial Discharge Transformer is a specially designed high voltage test transformer used for partial discharge measurement and power frequency withstand voltage testing of electrical equipment.

Unlike conventional test transformers, this transformer adopts optimized insulation structure, high-quality transformer oil insulation and advanced shielding technology to minimize internal partial discharge and electromagnetic interference during high voltage testing.

It provides a clean and stable high voltage test source for transformer manufacturers, GIS manufacturers, power equipment companies, research institutes and high voltage laboratories.

The transformer is widely used for insulation performance verification of power transformers, cables, switchgear, bushings, insulators and other high voltage components.

Working Principle

Working Principle of Oil-immersed Non-Partial Discharge Transformer

During high voltage testing, partial discharge generated inside the test equipment itself may affect the accuracy of measurement results.

The Oil-immersed Non-Partial Discharge Transformer is designed to reduce its own discharge level through:

• Optimized electric field distribution
• High insulation strength oil insulation system
• Multi-layer electromagnetic shielding structure
• Low-noise transformer design
• Improved insulation coordination

The transformer provides a stable AC high voltage output with extremely low background discharge, allowing accurate detection of partial discharge signals from the tested equipment.

This makes it especially suitable for sensitive insulation tests where accurate PD measurement is required.

Key Features

Main Features of SUTE Oil-immersed Non-Partial Discharge Transformer

Ultra-low Partial Discharge Performance

The transformer is designed with optimized insulation materials and shielding technology to achieve very low partial discharge levels, helping improve the accuracy of insulation testing.

High Insulation Reliability

The oil-immersed structure provides excellent electrical insulation and heat dissipation performance, ensuring stable operation under high voltage conditions.

Low Electromagnetic Interference

Multi-layer shielding technology effectively reduces external interference and improves measurement reliability during partial discharge testing.

Low Waveform Distortion

The optimized magnetic circuit and winding structure provide high-quality output voltage waveform suitable for precision high voltage testing.

Flexible Customized Solutions

SUTE can customize voltage levels, capacity ratings and configuration according to different testing requirements.

Technical Specifications

Technical Parameters

Technical parameters can be customized according to customer testing requirements.

Applications

Applications of Non-Partial Discharge Test Transformer

The SUTE Oil-immersed Non-Partial Discharge Transformer is widely applied in:

Transformer Testing

Used for power transformer insulation tests, induced voltage tests and partial discharge measurement.

GIS Testing

Provides a low-noise high voltage source for gas insulated switchgear insulation testing.

Cable Testing

Suitable for high voltage cable withstand voltage and insulation quality evaluation.

Electrical Equipment Testing

Used for testing:

• Circuit breakers
• Bushings
• Insulators
• Instrument transformers
• Other high voltage components

High Voltage Laboratories

Ideal for universities, research institutes and electrical testing laboratories.

Advantages of SUTE

Why Choose SUTE Non-Partial Discharge Transformer?

Professional High Voltage Testing Equipment Manufacturer

SUTE focuses on the design and manufacture of high voltage testing equipment, providing complete solutions for electrical insulation testing.

Advanced Design Capability

Our engineering team develops customized testing transformers according to voltage level, capacity and application requirements.

Reliable Manufacturing Quality

Each system is manufactured with strict quality control to ensure stable performance during high voltage testing.

Complete Testing Solutions

The transformer can be integrated with:

• Partial discharge measurement systems
• Voltage dividers
• Resonant test systems
• Control and measurement units

to build complete high voltage testing platforms.

Standards and Testing Requirements

Applicable Testing Standards

The Oil-immersed Non-Partial Discharge Transformer is designed for high voltage testing applications following relevant international testing principles, including:

• IEC 60060 High Voltage Test Techniques
• IEC 60270 Partial Discharge Measurements
• IEC 60076 Power Transformer Testing

Partial discharge testing is an important method for evaluating insulation defects in high voltage equipment, and accurate measurement requires a low-background-discharge testing environment.

FAQ

Frequently Asked Questions

What is a non-partial discharge transformer?

A non-partial discharge transformer is a specially designed high voltage test transformer with extremely low internal partial discharge characteristics, used to provide a clean high voltage source for insulation testing.

Why is partial discharge performance important in high voltage testing?

Partial discharge generated by the test transformer itself may interfere with measurement results. A low partial discharge transformer helps improve the accuracy of insulation evaluation.

What equipment can be tested with this transformer?

It can be used for testing transformers, GIS, cables, switchgear, bushings, insulators and other high voltage electrical equipment.

Can SUTE customize the transformer?

Yes. SUTE provides customized solutions according to required voltage level, capacity, installation environment and testing requirements.
